High Purity Certificated Pressure Absorption Oxygen Generation System PSA Medical Oxygen Generator for Hospital
- Overview
- Recommended Products
Introducing, the Hengyetong’s High Purity Certificated Pressure Absorption Oxygen Generation System, a top-of-the-line medical oxygen generator designed for hospitals. This innovative system is specifically engineered to provide a reliable and efficient source of oxygen for medical facilities, ensuring that patients receive the high-quality care they deserve.
The Hengyetong’s oxygen generator utilizes Pressure Swing Adsorption (PSA) technology to extract oxygen from the surrounding air, producing a pure and clean supply of medical-grade oxygen. This not only eliminates the need for traditional oxygen cylinders but also ensures a continuous and on-demand supply of oxygen for patients in need. With its high purity certification, hospitals can rest assured that the oxygen generated by this system meets the strictest medical standards.
One of the key features of the Hengyetong’s oxygen generator is its pressure absorption capabilities, which allow for the efficient separation of oxygen from other gases in the air. This process results in a consistent and reliable supply of oxygen that can be adjusted to meet the specific needs of patients. Furthermore, the system is designed to be user-friendly and easy to operate, making it ideal for busy hospital settings where time is of the essence.
Not only does the Hengyetong’s oxygen generator provide a cost-effective solution for hospitals, but it also offers peace of mind knowing that patients are receiving a safe and reliable source of oxygen. Its compact design and quiet operation make it a versatile and convenient option for medical facilities of all sizes.
The Hengyetong’s High Purity Certificated Pressure Absorption Oxygen Generation System is a top-quality product that is sure to meet the oxygen needs of hospitals and medical facilities. With its advanced technology, high purity certification, and user-friendly design, this oxygen generator is the ideal choice for providing patients with the care they deserve. Trust Hengyetong for all your medical oxygen needs
|
Model
|
Orygen Purity
|
Dxygen Capacity - Nm³/min
|
Air Compressor - KW
|
Suitable Scale - Bed/pec
|
Power - KW
|
|
MPS93-2
|
≥93
|
5
|
7.5
|
150
|
8.0
|
|
MPS93-10
|
≥93
|
10
|
11
|
300
|
12
|
|
MPS93-50
|
≥93
|
50
|
45
|
1500
|
48
|
|
MPS93-120
|
≥93
|
120
|
110
|
3600
|
115
|
Q: What the oxygen purity of this machine can be achieved
This is our high purity model, it is can be produce 99%~99.7% oxygen purity.
Q:The more information you kindly tell us, the better professional service we provide for you
a. What is the gas source you currently use? cylinder/dewar/liquid gas/other
b. Gas consumption? Nm3/h, L/min
c. Required gas pressure
d. Required gas quality? eg:Maximum oxygen percentage, Maximum moisture content, etc
Q: Oxygen equipment is safety
Definitely! Nitrogen/Oxygen generator is a kind of air separation device under normal temperature, it can supply stable and continuous nitrogen/oxygen gas, it doesn’t need any high pressure cylinders and liquid cylinders which have potentially dangerous; so we don’t need to worry about no timely supply due to special circumstance.
Q: The producing nitrogen/oxygen is gaseous state or liquid state
Our nitrogen/oxygen equipment use PSA air separation technology under normal temperature, with no-low temperature operation, the temperature of nitrogen/oxygen product is close to ambient temperature.
Q: How long is the nitrogen/oxygen equipment service life
Generally speaking, industrial equipment service life is depend on daily maintenance. under normal maintenance, our equipment can well running for more than 10 years.
Q: How is the maintenance time of oxygen equipment
For Air purification module: the primary filters need to replace after 4000h normal operation; precision, extra-precision filters need to replace after 8000h,12000h normal operation; valve seal seal for 16000h;other filters depend of actual operation.
